Product Details:
|
| Product Name: | 15kHz Digital Ultrasonic Welding Generator | Output Power: | 800-2600w |
|---|---|---|---|
| Power Supply: | AC220V 50Hz | Power Fluctuation: | ≤ 5% |
| Usage: | Plastic Welding,Ultrasonic Plasitc Welder For ABS PP PE PC Material,ultrasonic Welding | Frequency: | 15KHz |
| Dimensions(L*W*H): | 400mm*195mm*98mm | After-sales Service Provided: | Online Support,Video Technical Support |
| Warranty: | 1 Year | Application: | Ultrasonic Plasitc Welder,Ultrasonic Welding Machine,Non Woven Sealing |
| High Light: | 5% Fluctuation Ultrasonic Welding Generator,4 Core 32 Bit Ultrasonic Generator,2600W ultrasonic weld generator |
||
15khz 2600w Digital Ultrasonic Welding Generator For Non-Woven Fabric Welding
The ultrasonic system is divided into three parts, ultrasonic generator, ultrasonic transducer, and ultrasonic horn/mold, a complete ultrasound system. This is the 15khz 2600w digital ultrasonic welding generator for non-woven fabric welding. The ultrasonic welding generator produces a higher than 20KHz audio electrical signal, through the piezoelectric inverse effect of the transducer converted into a mechanical oscillation of the same frequency, and in the form of super audio longitudinal wave radiation. The digital generator failure rate is low, consumables, durable, easy installation and debugging, maintenance is simple.
Technical parameters:
| Product Name | Digital Ultrasonic Welding Generator |
| Output power | 800-2600w |
| Power supply | AC220V 50Hz |
| Power fluctuation | ≤ 5% |
| Capacitance | 9nf |
| Frequency | 15KHz |
| Dimensions(L*W*H) | 400mm*195mm*98mm |
| After-sales service provided | Online support, Video technical support |
| Warranty | 1 Year |
| Application | Ultrasonic Plastic Welder, Ultrasonic Welding Machine, Non-Woven Sealing |
Features:
* 4-core 32-bit processor
* Real-time frequency automatic tracking display
* Amplitude division function
* Welding amplitude 10%--100% adjustable (1% accuracy)
* Mold impedance analysis+protection
* The ultrasonic welding generator also has overload protection
* Modular integrated circuit, easy for maintaining and repairing.
* The output power is bigger compared with other brands
* Fuse to protect the machine, cooling device for protecting the ceramic transducer.
* Use special plugs and sockets for the best connection to avoid a bad connection of the machine.
* Automatic overload protection device against the inaccurate operation.
Application:
Automotive | Auto and motorcycle plastic parts, battery, glove box, Plastic fuel tank, Intake manifold, Plastic muffler, Expansion Tank, front corner lamp, etc. |
Electronics | recording, audio tape boxes and core wheel, disk enclosure, etc |
Home appliances | Balance ring, electronic clock, electric trumpeter hairdryer, steam iron water tank, etc |
Toy | plastic toys, water guns, aquatic life video game, etc |
Packaging | Plastic pallet, Corrugated tray, etc |
Medical | Surgical Instruments, Testing Equipment, filters, I-V units, insulated trays..etc. |
