Product Details:
|
| Product Name: | 2500W Ultrasonic Welding Generator | Frequency: | 15KHz |
|---|---|---|---|
| Frequency Tuning Method: | Auto Tuning | Output Power: | 2500W |
| Weight: | 6kg | Power Supply: | 220V/110V±10% |
| Usage: | Plastic Welding,Ultrasonic Plasitc Welder For ABS PP PE PC Material,ultrasonic Welding | Working Mode: | Time,energy,grounding |
| High Light: | PLC Control 15KHz Ultrasonic Welding Generator,2500W Ultrasonic Welding Generator,Auto Tuning Ultrasonic Generator |
||
15KHz 2500W Digital Ultrasonic Welding Generator Plastic Welding
The central element of an ultrasonic system is the ultrasonic generator, which provides electrical energy to the ultrasonic transducers. The ultrasonic generator will receive and convert energy from the power source to the proper frequency, voltage, and amperage for the ultrasonic transducer(converter and booster).
The ultrasonic generator series has a real-time frequency automatic tracking function and four working modes(continuous, time, energy, and grounding) and has proved very stable quality in the market. The control system of the generator can cut the power supply when there is any malfunction during the ultrasonic working process, making it safer and more reliable. The digital ultrasonic welding generators can be applied in the continuous non-woven fabric welding and cutting, plastic welding, and food cutting industries, etc. Different powers of this series are available.
Technical parameters:
| Frequency | Power | Frequency Range | Voltage | Air source | Weight |
| 15kHz | 2500w/3000w/4000w | 14.40-15.20kHz | 220V+-10% | filtered clean air | 7kg |
| 20kHz | 1500w/2000w/3000w | 19.40-20.20kHz | 220V+-10% | ||
| 30kHz | 750w/1000w/1500w | 29.30-30.30kHz | 220V+-10% | ||
| 35kHz | 750w/1000w | 34.20-35.40kHz | 220V+-10% | ||
| 40kHz | 750w/1000w | 39.20-40.40kHz | 220V+-10% |
Features:
* Amplitude segmentation function: In the fixed amplitude mode, the only segment A amplitude can be adjusted；In the segmentation amplitude mode, segment A and segment B can be adjusted.
* Working amplitude adjustable 10-100% with an accuracy of 1% makes the generator easy to increase or decrease the amplitude value so as to reach satisfied welding result;
* Amplitude compensation method can maintain the consistency of the welding effect.
* Real-time frequency automatic tracking function solves the problem of resonant frequency drift in the work of the transducer and ensures the output efficiency of the transducer;
* Four Welding modes:
1. Continuous mode, with ultrasonic time adjustment range 0 - 99 min 59 sec;
2. Time mode, with ultrasonic time adjustment range 0 - 9.99S;
3. Energy mode, with ultrasonic energy adjustment range 0 - 50000J;
4. Grounding mode, with ultrasonic grounding holding time range 0 - 9.99S;
* Protection Function: overload protection, voltage protection (input), transducer voltage protection, mold impedance analysis + protection
Application:
| Automotive | car door welded baffle welding, automobile, car mats welding, automotive bumper repair welding, cotton insulation doors, engine cover, radiator cap spot, etc |
| Electronics | Switches and sockets, electronic swatter, remote control unit, etc |
| Home appliances | computer, electronic clock, electric kettle air-Hsiang, , etc |
| Toy | plastic toys, plastic gifts, etc |
| Packaging | Corrugated tray, hollow crate welding, zip lock welded, etc |
| Medical | Testing Equipment,filters,I-V units,insulated trays..etc. |
FAQ:
1.When can we get the reply?
We will reply within 24 hours.
Our KnmTech sales team will try our best to support you.
2.What about minimum order quantity?
No limit, only one set can also be accepted.
3.How will you control product quality?
We strictly control the production process, and every product is tested and confirmed to be fine by our QC team before delivery.
Detailed Photos:
